Hunter ceiling fan User Manual

www.HunterFan.com
1.888.830.1326
Wiring
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
Using an orange wire
connector from
the hardware
bag, connect the
3 grounding wires
(green, green/yellow
stripe, or bare copper)
coming from the
ceiling, downrod, and
hanging bracket.
F
R
O
M
R
E
C
E
I
V
E
R
F
R
O
M
C
E
I
L
I
N
G
F
R
O
M
C
E
I
L
I
N
G
B
R
A
C
K
E
T
green/yellow stripe (grounding)
green/yellow stripe
green/yellow stripe
black blue
yellow blue
Note: To connect the
wires, hold the bare
metal leads together and
place a wire connector
over them, then twist
clockwise until tight.
Using the orange
wire connectors
from the remote
control hardware
bag, connect the blue
wire from the receiver
to the blue wire (or
possibly black with
white stripe wire) from
the fan. Connect the
yellow wire from the
receiver to the black
wire from the fan.
F
R
O
M
F
A
N
F
R
O
M
F
A
N
F
R
O
M
R
E
C
E
I
V
E
R
Using the orange wire
connectors from
the hardware bag,
connect the black wire
(ungrounded) from
the ceiling to the black
wire from the receiver.
Connect the white
wire (grounded) from
the ceiling to both the
white wire from the
receiver and the white
wire from the fan.
F
R
O
M
C
E
I
L
I
N
G
black (ungrounded) white (grounded)
black white
F
R
O
M
F
A
N
white
10
M0065-01 • 05/13/14 • © Hunter Fan Company
