Rocker- Style Plate
Switch Cover Plate
Removed Tabs
To install the transmitter cradle, remove the
two screws holding the switch cover plate. Do
not remove the cover plate. Orient the cradle
by lining up the two mounting holes with
those on the cover plate. Insert and tighten
the screws. Do not over tighten.
Note: For rocker-style cover plates, break off
the tabs by pushing outward.
To turn on fan, press a fan speed button. Speeds
range from off (0) to high (3). Quickly press the
Light button to turn the lights off and on.
Medium
Speed
Light
High
Speed
Fan
Off
Low
Speed
Operation, Maintenance, & Cleaning
To switch the direction of air ow, move the
reverse switch to the opposite position.
Reverse
Switch
18
M0065-01 • 05/13/14 • © Hunter Fan Company
