Height Adjustment
Knob
Metal Ring
L-shaped Screw
5
61302-01 R20151201
3. Carefully remove the fuse from the clips holding
it on the top and bottom. Figure 3.
Warning! Electrical Hazard! Only replace
with a fuse type and rating matching what was
removed from the product. If the product fails a
second time, immediately unplug it and contact our
technical support at 1-888-880-3267.
FAN ASSEMBLY
Figure 3.
Figure 4.
Figure 5.
4. Gently push the fuse back into the pins that will
hold it in place.
Note: If the fuse is not seated properly, the unit
will not function.
5. Slide the door back over the fuse box in the plug.
1. Remove the L-shaped screw and metal ring
from the telescopic pole by turning the L-shaped
screw counter clockwise. (Figure 4)
2. Insert the telescopic pole into the top of the
base. Install the L-shaped screw and metal
ring back into the threaded hole at the bottom
of the telescopic pole to secure the pole to the
base. (Figure 4)
3. Turn the base back upright.
4. Grasp the telescopic pole firmly and loosen the
height adjustment knob. (Figure 5)
5. Raise the inner pole to desired height and
tighten the height adjustment knob. (Figure 5)
6. Plug the fan back in and resume use.
