41343-01 7/1/2002
Table 7-1
Fan with no light
fixture included See Figure 7c
Fan with single-
globe light fixture See Figure 7c
included
Fan with multi-
light light fixture See Figure 7d
included
Fan with integra-
ted single globe See Figure 7e
If your fan has a lower switch hous-
ing as shown in Figure 7c, and you
ARE installing an accessory light kit
or single-globe light fixture included
with your fan, go directly to STEP
8 - INSTALLING LIGHT FIXTURE.
Figure 7c
Figure 7d
ATTACHING THE LOWER SWITCH
HOUSING
Your hunter fan includes one of two
lower switch housings. Both lower
switch housings are shown in Figures
7c, 7d and 7e. The type of lower
switch housing you have depends on
whether your fan includes a light fix-
ture, and if so, what type of light fix-
ture it is. Use table 7-1 to assist you.
Figure 7e
continued
To Next Page
