Hunter 33
6.12
Bottom Thru Hulls
1. ENGINE PICKUP 6. MACERATOR DISCHARGE
2. AFT VANITY DISCHARGE 7. OPTIONAL AFT HEAD PICKUP
3. GALLEY DRAIN 8. OPTIONAL AC PICKUP
4. KNOT TRANSDUCER 9. OPTIONAL OVERBOARD AFT DISCHARGE
5. DEPTH TRANSDUCER
