CONNECTING SENSORS OR FLOW METERS (OPTIONAL)
An HPC-congured controller supports most open/closed contact sensors, such as
Hunter rain and soil moisture sensors.
1. Connect one sensor wire to one of the two SEN ports on the controller.
2. Connect the other sensor wire to the other SEN port on the controller.
3. Congure in the Hydrawise app.
For full details, refer to the instructions
provided with your sensor or ow meter.
Once you've wired your sensor, you must
congure it in your Hydrawise account.
See Conguring Sensors
hydrawise.com/support for full
instructions on setting up sensors.
Wiring for standard Hydrawise ⁄" (20 mm) or
1" (25 mm) ow meters is as follows:
Flow Meter Wire Label on Controller
Blue
SEN
White
SEN
Red Not connected
Wiring for open/closed contact sensors is as follows:
Sensor Wire Label on Controller
Normally Open /
Normally Closed wire
SEN
Second (common) wire
SEN
