Installing the Pull Chains
The fan pull chain controls
the speed: from high to off.
The light pull chain controls
the light xture: on and off.
Repeat x2
Remove and discard the plastic
connectors from the ends of the short
pull chain. Feed the pull chains from
the fan switch and the light switch
down through the holes in the upper
switch housing as shown. Attach the
pull chain pendants to the light and
fan pull chains.
Reverse
Switch
Ceiling fans work in two directions: downdraft and updraft.
To change the direction of air ow, turn the fan off and let
it come to a complete stop. The reversing switch is located
inside the light xture. It can only be accessed when the glass
is removed. Slide the reversing switch to the opposite position.
Restart the fan.
Updraft (clockwise rotation)
creates a more indirect airow.
Updraft airow is great for
moving warm air downward.
Downdraft (counterclockwise
rotation) creates a direct breeze
and maximum cooling effect.
