11
42650-01•07/30/07•HunterFanCompany
GlassBowl
Bulb
Installing the Glass Bowl
8-1. Partially install two screws in the upper light kit.
8-2. Alignthekeyholesintheupperlightkitringwith
the partially installed screws and rotate to situate
the screws in the narrow ends of the keyholes.
8-3. Installtheremainingscrewintotheupperlightkit
ring and securely tighten all three screws.
8-4. Install bulb.
8-5. Alignthetabsintheglobeassemblywiththetabs
in the light kit ring, then lift the globe assembly
and rotate to engage the tabs. Make sure all tabs
are properly engaged before releasing the globe.
Steps 8-1 - 8-3
Steps 8-4 - 8-5
Screws
8 • Completing Your Installation With a Bowl Light Fixture
