3 • Assembling and Hanging the Fan
WARNING: Fan may fall if not assembled as directed in these
installation instructions.
3-1.Unbundlethewiresfromthefan.
For Standard or Angle mounting:
3-2.Insertthedownrodthroughthecanopyandcanopytrimring.
Feed the wires from the fan through the downrod on one side of
the pin in the ball.
3-3.Loosenthesquareheadsetscrewontheadaptertoinstallthe
pipe and ball assembly. Note: When the pipe and ball assembly
isfullyinstalled,2-3threadsonthepipewillstillbevisible;thisis
normal. Securely retighten the set screw with a wrench or pliers.
Skiptostep3-7.
CAUTION: e adapter has a special coating on the threads. Do
notremovethiscoating;thecoatingpreventsthedownrodfrom
unscrewing.Onceassembled,donotremovethedownrod.
For Low Profile mounting:
Note: For low profile mounting, the downrod is replaced with the
low profile washer.
3-4. Removethesetscrewfromtheadapter.
3-5.Placethelowprolewasherintothecanopywiththelipdown.
3-6.Aligntheholesinthewasherwiththeholesintheadapter.
Assemblesecurelywiththreelowprolescrews.
Hanging the Fan:
Note: To hang the fan, you must tilt the canopy to an almost vertical
position so that the canopy slots sit on the ceiling plate hooks.
3-7.Raisethefanandaligntheslotsinthecanopywiththehookson
the ceiling plate.
3-8. Placetheslotsoverthehookstohangthefan.
Steps 3-2 – 3-3
Low Profile
Washer
Downrod
Canopy
Set Screw
Low Profile Screw
Canopy
TrimRing
Green
Ground
Wire
Standard or Angle Mounting
Low Profile Mounting
Low Profile Screws
Canopy
Canopy
TrimRing
Adapter
Low Profile
Washer
Low Profile Screw
Steps 3-5 – 3-6
Step 3-6 (Detail)
