5.7 - Awning with AUTOMATIC hook-up of fabric on opening: “FTC” function
This function enables automatic connection and disconnection of the awning. The “FTC” function can only be activated if the automatic fabric connect/disconnect
mechanism is present on the awning, in a single position, located in alignment with the awning opening position. The motor enables memorisation of only one hook-
up position.
Ingeneralthistypeofmechanismhasastopformechanicalconnectionoftheawningandtwoadditionalpoints(positionedbeyondthestop)whichtheawningmust
reach to enable connection (in position “1”) and disconnection (in position “S”) of the canvas.
Thereforetoensurecorrectoperationofthismechanism,thetwopositions“1”and“S”mustbesetandmemorisedasdescribedbelow.
“1”
( )
S
Caution!
•Beforeprogrammingthe“FTC”function,ensurethatlimitpositions“0”and“1”havenotbeenmemorised;ifnecessary,cancelthemaccording
toprocedure5.9.•Position“1”mustbelocatedafewcentimetresbe yondthemechanicalconnectionstop.Duringopening.thiswillenablethe
canvastoreachrstposition“1”andthenhookuptothemechanicalstopduringascent.•Position“S”mustbelocatedafewcentimetresbe yond
thedisconnectionmechanism.Duringclosure,thiswillenablethecanvastoreachrstposition“S”,automaticallydetachfromthemechanicalstop
and then raise to the closing limit position “0”.
• (The “RDC” function remains enabled)
01. UsetheUp or Down button to move the awning to the point of mid-travel.
02. Press and hold Up until the awning stops automatically at limit switch “0”; then release the button.
03. Press and hold Down and move the awning beyond the hook-up point, stopping it a few centimetres further than this point (if necessary correct the position using
the two buttons).
04. Press and hold the Up and Down buttons simultaneously and wait for the awning to complete two short movements: one up movement and (after a few seconds)
one down movement, until it stops again in the set position. Then release the two buttons.
05. Press and hold both the Up and Down buttons simultaneously until the awning performs a short up movement. Then release the two buttons.
06. UsetheUp and Downbuttonsagaintomovetheawningtodisconnectposition“S”.
07. Press and hold the Up and Down buttons simultaneously and wait for the awning to complete two short movements: one up movement and (after a few seconds)
one down movement, until it stops again in the set position. Then release the two buttons.
04
06
0201
“1”
( )
S
03
5
sec.
5
sec.
05
“1”
( )
S
07
5
sec.
THE
END
“0”
2 1
2
“1”
“S”
• (It disables the “RDC” function)
01. UsetheUp or Down button to move the awning to the point of mid-travel.
02. Press and hold Up and wait for the awning to stop automatically at limit switch “0”(donotreleasethebutton!).
03. With the Up button still pressed, press and hold the Down button at the same time and wait for the awning to complete a short down movement; then release
the two buttons.
04. Press and hold the Up and Down buttons simultaneously and wait for the awning to complete two short movements: one up movement and (after a few seconds)
one down movement, until it stops again in the set position. Then release the two buttons.
05. Press and hold both the Up and Down buttons simultaneously until the awning performs a short up movement. Then release the two buttons.
