VM Series Maintenance and Safety Manual 704-0212-209 Operation Requirements 2- 9
Auto Mode Operations
• Doors must be closed to start a program and must remain closed while the
program is running.
• Doors may be opened when the program is complete.
• Doors may be open for Check for Errors or Estimated Run Time.
• Doors can be opened at a Position Stop Block or M00/M01 command, but
must be closed prior to pressing Start Cycle to resume the program.
• Select the Interrupt console key and the doors unlock after axis motion is
completed.
• In Interrupt mode, doors are allowed to be opened after all axes, spindle,
and ATC operations are stopped. The doors must be closed prior to
pressing the Auto console key then press the Start Cycle console key to
resume the program.
Persons Trapped in Machine
Closing the enclosure door with control power Off locks the door; therefore, it is possible
for a person to be locked inside the enclosure.
If all safety circuits are intact, it is not possible to run an automatic operation while a
person is in direct contact with any axis, spindle, the tool changer, chip conveyor or chip
auger.
Releasing a Person Trapped Inside the Machine Enclosure
To release a person trapped inside the machine enclosure, where the machine is
functionally sound (i.e., the machine functions as intended), follow these steps:
1. Release the Emergency Stop button.
2. Press the Manual console key.
3. Press the Power On button.
4. Press the Start button. The enclosure doors will automatically unlock.
Do not close enclosure doors while performing maintenance inside
the machine enclosure.
Never perform maintenance inside the machine enclosure without
someone else present.
Pressing the Emergency Stop button will lock the enclosure doors.
