STORAGE
Mounting the compressor to the wall.
NOTE: DO NOT RUN COMPRESSOR WHILE IT IS MOUNTED TO
THE WALL. TO USE REMOVE FROM WALL BRACKET.
1. Find proper mounting location on the studs. Not lower than
3.5 ft from the floor.
2. Mark a level line on the wall.
3. Mark the position of the holes on the studs using the
bracket as a template. (Fig.1)
4. Pre-drill the holes in to the studs using a 1/8” drill bit (not
included).(Fig.1)
5. Mount the wall bracket onto the studs using four screws and
washer provided.(Fig.2)
y Assemble four screws and washers into the pre-drilled holes.
y Tension the screws firmly into place.
6. After fastening make sure the wall bracket is level and securely
mounted onto the wall.
7. Hang the unit onto the wall bracket. (Fig. 3)
