To Next PageTo Next PageWhat causes a Husqvarna 135 to flood when the engine is not running?
If your Husqvarna Chainsaw is flooding when the engine isn't running, it might be due to a worn needle valve, a needle valve set too high, or a needle valve assembly sticking.
Why Husqvarna Chainsaw will not “four-stroke”?
If your Husqvarna Chainsaw will not “four-stroke”, it might be due to a blocked fuel tank vent, a blocked fuel filter, a blocked fuel line, or a loose or damaged fuel hose. Other potential issues include a leaking or blocked impulse channel, a loose cover on the carburettor pump side, a faulty pump diaphragm, a leaking air intake hose, loose carburettor mounting bolts, a needle valve set too low, a leak in the metering system, an incorrectly assembled metering unit, a loose diaphragm rivet, a hole in the diaphragm, or a leaking control diaphragm/cover plate.
Why my Husqvarna 135 will not run at full throttle?
If your Husqvarna Chainsaw won't run at full throttle, consider these possible solutions: Adjust the H screw. Check for blockages in the air filter, fuel tank vent, or fuel filter. Inspect the fuel line and fuel hose for damage. Also, look for a leaking or blocked impulse channel, a loose cover on the carburettor pump side, a faulty pump diaphragm, a leaking air intake hose, loose carburettor mounting bolts, a needle valve set too low, a damaged or incorrectly assembled metering system, a leaking control diaphragm/cover plate, a sticking needle valve assembly, or a blocked silencer.
What to do if my Husqvarna Chainsaw does not accelerate?
If your Husqvarna Chainsaw isn't accelerating, try the following: Adjust the L and H screws. Check for blockages in the air filter, fuel tank vent, or fuel filter. Also, inspect the fuel line and fuel hose for damage. Other potential issues include a blocked impulse channel, loose cover on the carburettor pump side, a faulty pump diaphragm, a leaking air intake hose, loose carburettor mounting bolts, incorrect needle valve setting, a misassembled metering system, sticking needle valve assembly, faulty diffuser jets, or a blocked silencer.
What causes too much fuel at idling on Husqvarna Chainsaw?
If there's too much fuel at idling on your Husqvarna Chainsaw, it could be due to a needle valve set too high, a needle valve assembly sticking, a damaged metering system, a worn needle valve, a leaking control diaphragm/cover plate, or a metering system incorrectly assembled.
Why does the L screw requires constant adjustment on my Husqvarna 135?
If the L screw on your Husqvarna Chainsaw requires constant adjustment, it could be due to a blocked fuel line, a needle valve set too high, a needle valve assembly sticking, a leak in the metering system, a leaking control diaphragm/cover plate, faulty diffuser jets, or a crankcase leaking.
What causes over rich acceleration in Husqvarna Chainsaw?
If your Husqvarna Chainsaw experiences over rich acceleration, possible causes include the need to adjust the L screw or the H screw, a blocked air filter, a faulty pump diaphragm, or faulty diffuser jets.
Why is my Husqvarna 135 Chainsaw idling uneven?
If your Husqvarna Chainsaw is idling unevenly, consider these potential causes: a blocked fuel filter, a blocked fuel line, a leaking air intake hose, loose carburettor mounting bolts, a worn throttle valve pivot, a loose throttle valve screw, a worn throttle valve, a sticking needle valve assembly, a leak in the metering system, a worn metering system centre knob, a hole in the diaphragm, a leaking control diaphragm/cover plate, or a crankcase leak.
What causes idling too rich on Husqvarna 135 Chainsaw?
If your Husqvarna Chainsaw is idling too rich, consider these possible causes: Adjust the L screw. Other potential issues include a worn needle valve, a needle valve set too high, a worn needle valve lever, a leaking control diaphragm/cover plate, or a needle valve assembly sticking.
How to fix Husqvarna 135 starting failure?
If your Husqvarna Chainsaw fails to start, several factors could be the cause. It might be due to binding pawls, which can be resolved by adjusting, cleaning, or replacing them. Ensure you are using the correct fuel type; if not, drain the incorrect fuel and refill with the appropriate type. Also, check the spark plug: it should be dry, clean, and properly gapped. If the spark plug is loose, retighten it. Finally, adjust the idling speed using the T-screw.
General| Cylinder Displacement | 40.9 cm³ |
|---|---|
| Weight | 4.4 kg |
| Sound Pressure Level | 102 dB(A) |
| Sound Power Level | 114 dB(A) |
| Bar Length | 14 in |
| Chain Pitch | 3/8 inch |
| Chain Gauge | 0.05 in |
| Oil Tank Volume | 0.25 liters |
Explains symbols found on the chainsaw itself.
Explains symbols used within the operator's manual.
Identifies and explains safety labels found on the chainsaw.
A welcoming message from the manufacturer.
Identifies and lists the parts of the chain saw with corresponding numbers.
Initial checks and actions before operating the chainsaw for the first time.
Key safety advice and general warnings for using the chainsaw.
Lists and describes essential personal protective gear for chainsaw users.
Explains the safety features integrated into the chainsaw.
Details the function and operation of the chain brake and front hand guard.
Explains the function of the throttle lockout mechanism.
Details the system designed to reduce vibration during operation.
Explains how to use the stop switch to turn off the engine.
Guidance on choosing and maintaining cutting equipment.
Information on selecting equipment to minimize kickback.
Instructions on sharpening cutting teeth and setting the depth gauge.
Detailed steps for adjusting the depth gauge setting.
Instructions on how to properly tension the saw chain.
Guidance on lubricating the bar and chain for optimal performance.
Steps to check if the chain is receiving sufficient lubrication.
How to inspect the chain and guide bar for wear.
Step-by-step guide on how to attach the bar and chain to the saw.
Information on the correct type of gasoline and mixing ratio for the engine.
Guidance on selecting and using the correct chain oil.
Precautions and steps for safely refueling the chainsaw.
Safety rules related to handling fuel and preventing fires.
Detailed steps for starting the chainsaw, including cold and warm engine procedures.
Instructions on how to safely shut down the chainsaw engine.
Pre-operation checks and safety rules before using the chainsaw.
Basic safety rules and advice for general chainsaw operation.
Explains fundamental techniques for cutting with a chainsaw.
Detailed explanation of kickback causes and prevention methods.
Techniques for cutting logs efficiently and safely.
Instructions and safety precautions for felling trees.
The process of felling a tree using directional and felling cuts.
Explains kickback and how to prevent it.
How to adjust the carburetor for optimal engine performance.
Procedures for inspecting and maintaining safety features.
Checks the muffler for damage and proper attachment, including spark arrestor.
Step-by-step instructions for replacing the starter cord.
Maintenance procedures for the air filter to prevent malfunctions.
Checks and maintenance for the spark plug, including gap adjustment.
Instructions for lubricating the bar tip sprocket.
Cleaning and maintaining the cooling system for the engine.
Special measures for operating the machine in cold weather.
A schedule detailing daily, weekly, and monthly maintenance tasks.
Specifications related to the engine, including displacement and power.
Specifications for fuel and oil tank capacities and pump capacity.
Specifications for standard bar length, pitch, and chain dimensions.
Specifications related to the engine for different models.
Specifications for fuel and oil capacities for different models.
Chain and bar specifications for different models.
Lists recommended bar and chain combinations meeting US safety standards.
Lists recommended bar and chain combinations meeting Canadian safety standards.
Recommended type-approved combinations of guide bars and saw chains.
Outlines the rights and responsibilities of the owner regarding the warranty.
Lists the owner's duties to maintain warranty coverage.
Lists parts covered under the emissions control system warranty.
Instructions on how to contact Husqvarna for warranty claims.
Information on obtaining warranty service from authorized dealers.
General safety guidelines for individuals using chain saws.
Specific safety measures to prevent kickback injuries.
Additional safety advice for operating chain saws.
