Husqvarna FE 450 2016 User Manual

17 TUNING THE ENGINE 95
401951-10
–
Clean gear teeth

of the shift lever and shift shaft.
– Mount the shift lever on the shift shaft in the required position and engage the
gearing.
Info
The range of adjustment is limited.
The shift lever must not come into contact with any other vehicle compo-
nents during the shift procedure.
–
Locate and tighten screw

with washers.
Guideline
Screw, shift lever M6 14 Nm
(10.3 lbf ft)
Loctite
®
243™

Husqvarna FE 450 2016 Specifications

General

Engine Type	Single cylinder, 4-stroke
Bore x Stroke	95 mm x 63.4 mm
Transmission	6-speed
Seat Height	970 mm
Fuel Tank Capacity	9.5 L
Final Drive	Chain
Rear Suspension	WP monoshock
Ground Clearance	370 mm
Starter	Electric
Cooling	Liquid
Fuel System	Electronic Fuel Injection
Ignition	Electronic
Front Suspension	WP 48 mm USD fork
Front Brake	Disc
Rear Brake	Disc
Wheelbase	1485 mm
Displacement	449.3 cc
