4 VIEW OF VEHICLE
14
4.2 View of vehicle, rear right (example)
F02333-10
1
Fork compression adjuster
2
Switch-off button ( p. 17)
2
Horn button ( p. 18) (All EU models)
2
Light switch ( p. 18) (All EU models)
2
Turn signal switch ( p. 19) (All EU models)
3
Emergency OFF switch ( p. 19) (All EU models)
3
Start button ( p. 19)
4
Throttle grip ( p. 17)
5
Fork rebound adjustment
6
Foot brake lever ( p. 24)
7
Level viewer, engine oil
8
Shock absorber compression adjustment
9
Shock absorber rebound adjustment
bk
Level viewer for brake fluid, rear
