English – 25
Checking and adjustment of the
steering wires
The steering is controlled by means of wires.
These can in time become slack, which implies that
the adjustment of the steering becomes altered.
Check and adjust the steering as follows:
1. Dismantle the frame-plate by releasing the
screws (two on each side).
MAINTENANCE
Adjusting the parking brake
The parking brake is adjusted as follows:
1. Loosen the locking nuts (1).
2. Tension the cable using the adjuster screw (2)
until the play in the cable is taken up.
3. Tighten the locking nuts (1).
4. The parking brake should be checked again
after the adjustment has been made.
WARNING!
A poorly adjusted parking brake
can result in reduced braking
ability.
3. If necessary, the wires can be adjusted by
tightening the adjuster nuts on each side of the
steering collar. Do not tension the wires too
much, they should only be
tightened
against the
steering collar.
Support the wire so it does not twist.
If you tension only one side the steering wheel’s
centre position may change.
Check the wire tension as set out in point 2
after you have made the adjustment.
2. Check the tension of the steering wires by
pushing them together as shown in the dia-
gram. It should be possible to push them
together so that the distance between them is
half as much, without using unnecessary force.
