12 – English

ASSEMBLING AND ADJUSTMENTS

7 To secure the cutting deck from spring back, place a

wooden block between equipment frame and chassis.

8 Remove the two screws on the equipment frame.

9 Pull out the cutting unit.

10 Remove the wooden block.

Assemble the parts in the reverse order.

Seat adjustment

The seat has a jointed attachment on the front edge and can

be tipped forward.

The seat can also be adjusted lengthways.

Loosen the handles under the seat and adjust it forwards or

backwards to the desired position.

Steering wheel height adjustment

1 Remove the cover.

2 Loosen the nut.

3 Loosening the locking screw with a 4 mm hex key.

4 Adjust the height. The height can be adjusted approx. 40

mm.

5 Tighten the lock screw and nut. Reﬁt the cover.

WARNING! Observe caution to avoid

trapping your hand.

WARNING! Take care so that hands are not

trapped or injured by the locking hooks

when the seat is folded back.

WARNING! Do not adjust seat settings while

driving. Risk of unsafe manoeuvring.

13mm
