English-66
LUBRICATION
5. Gear lever
Remove the transmission cover, two screws.
Lubricate the joints and bearings on the left side with
an oil can.
Remove the rubber casing and lubricate the
hydrostatic transmission cable with an oil can.
Press the pedal a few times and lubricate again.
Replace the rubber cover.
Replace the transmission cover.
6. Transmission
The oil and filter should be changed by an authorised
service representative, as described in the Workshop
Manual.
7. Cutting unit
Remove the front cover.
Lubricate using an oil can:
A. The safety catch
- Joints and bearings
Lubricate using grease:
B. Interior plug
C. Groove for equipment frame
8. Three-point link
Lubrication nipple located behind right front wheel.
Lubricate with grease gun until grease appears.
Use molybdenum disulphide grease.
6008-209
6020-024
6020-004
6008-233
