English-69
LUBRICATION
12. Oil filter, change
1. Open the engine cover.
2. Drain the engine oil as described in “4. Engine oil”
on page 64.
3. Remove the oil filter. If necessary, use a filter
remover.
4. Wipe new, clean engine oil onto the seal for
the new filter.
5. Fit the filter by hand with + 3/4 turn.
6. Run the engine warm, then check that there are
no leaks around the oil filter seal.
7. Check the oil level in the engine, top up if
necessary. The oil filter holds 0.2 litres of oil.
13. Parking Brake Cable
Remove the transmission cover, see "5. Gear lever” on
page 66.
Unhook the spring (A) from the screw (B) if required.
Remove the cable’s rubber casing when lubricating.
Lubricate the cable with an oil can, press the brake
pedal a few times and lubricate again.
Replace the spring (A) and the transmission cover.
14. Transmission oil level
1. Check the oil level in the transmission by looking
through the air intake mesh. The oil level shall be
between the MIN and MAX markings on the oil
container when at +20°C.
If the oil needs to be filled, you must first remove
the transmission cover.
2. Unscrew the oil container’s cover and fill with SAE
10W/30 engine oil, class SF-CC, until the oil level
reaches the “MAX” mark. Then screw the oil
container’s cap into place and attach the
transmission cover.
IMPORTANT INFORMATION
Used engine or transmission oil is health-
impairing and must not be disposed of in the
ground or in nature.
Replaced filters must be handed in to the
workshop or other allotted placed for disposal.
Avoid skin contact; wash with soap and water in
case of spills.
8009-161
6020-005
B
A
6008-210
