ELECTRICAL SYSTEM
Workshop Manual Ed. 09-2012
Electric starting system
The starting system is composed of:
- ECU (1).
- Battery (2);
- Starter relay (3);
- Starter motor (4);
- Fuse box (5);
- Ignition (6);
- Transponder antenna (7).
- R.H. switch (8);
- Clutch lever microswitch (9).
- Neutral position sensor (10).
- Side stand sensor (11).
