HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.

VRL Merchandisers

PN_3155541_E 19

Figure B. System Diagram- Refrigeration Mode

(This diagram is applicable for 3-door models)

GDF 3.0 SHEET SIZE D

NOTES:

1. APPLICABLE STANDARDS / SPECIFICATIONS

ASME Y14.5M-1994, DIMENSIONS AND TOLERANCES

2. KEY PRODUCT CHARACTERISTICS PER EPR-0006 & IDENTIFIED WITH SYMBOL

3. MATERIAL- Error: No reference

4. REF -

SHEET 3 OF 4

P/N

REV

THIRD

ANGLE

PROJECTION

UNLESS OTHERWISE SPECIFIED

DIMENSIONS ARE IN INCHES.

FILTER

DRIER

CAP TUBE

CHECK

VALVE

EVAPORATOR

CONDENSER

CONDENSATE PAN

HGSV

RSV

COMPRESSOR

PRESSURE

SWITCH

FILTER DRIER
