36 tEchnIcal data
P/N 3034041_D U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
VRM Replacement Parts List
Component parts are specifically chosen for
propane exposure and therefore non-incendive
and non-sparkling. Component parts shall
be replaced with identical components, and
servicing shall be done by factory authorized
service personnel only, so as to minimize the
risk of possible ignition due to incorrect
parts or improper service.
Models
StandardParts
Description PartNumber VRM1B VRM2B VRM3B
PowerCord(NEMA5‐15P) 0521094 XX X
LightSwitch 3038707 XX X
SensorNTC4mtsGreen 3023554 XX X
SensorNTC4mtsOrange 3031571 XX X
ControlEliwellRTN400 3023537 XX X
ControlDisplayKDE 3023552 XX X
MainSwitch 3038707 XX X
SolidStateRelay10Amp 3025471 XX X
Rail‐Shelf(50") 3015493 XX X
ShelfClips(insertintoRail‐Shelf) 3009285 XX X
WireShelf(White)21X24.312 3015794 XX
WireShelfBottom(White)21X24.312 3015795 XX
WireShelf(White)21X24.812 3041925 X
WireShelfBottom(White)21X24.812 3041926 X
LedLightCTR4000K 3024564 XX
LedLightRH4000K 3024573 XX
DoorBlackMedTempLH 3025860 XX X
DoorTorsionDoorAssy 3017256 XX X
DoorGasket 3017271 XX X
DoorHandle 051007300 XX X
UpperLightedDisplay
PartNumber VRM1B VRM2B VRM3B
WhitePlexiglassDisplay1Doors 3041296 X
WhitePlexiglassDisplay2Doors 3020063 X
WhitePlexiglassDisplay3Doors 3016789 X
PowerSupply100W24VDC 3013744 XX X
LedLight24"Display 3004888 X
LedLight36"Display 3004891 X
LedLight48"Display 3004897 X
MagneticClipforLedLight 0523762 XX X
Refrigeration
PartNumber VRM1B VRM2B VRM3B
CondenserUnitAssyVRM1B 3042225 X
CondenserUnitAssyVRM2B 3019958 X
CondenserUnitAssyVRM3B 3022938 X
CompressorR290115V/60Hz1/4HP 3024061 XX X
CondenserMedTemp 3020001 XX X
CondenserFanMotorAssy8.25"(Motor,Blade&Brkt) 3054705 XX X
EvaporatorCoilVRM1B 0534325 X
EvaporatorCoilVRM2B 0547180 X
EvaporatorCoilVRM3B 3025973 X
EvaporatorFanMotor1200RPM 3055126 XX X
EvaporatorFanBlade8.25" 3055130 X
EvaporatorFanBlade7.00" 3055131 XX
EvaporatorFanMotorBracket 3058806 XX X
DistributorOrifice0.11in 3020662 XX
DistributorOrifice0.16in 3025975 X
CapillaryTube.049"x195" 3020535 XX X
FilterDrier704‐200 0530462 XX X
Heaters
PartNumber VRM1B VRM2B VRM3B
HeaterFrame115VVRM1B 3037337 X
HeaterFrame115VVRM2B 3022285 X
HeaterFrame115VVRM3B 3022286 X
SheelMetalReplacementPartsPainted
PartNumber VRM1B VRM2B VRM3B
SupportPostRearPanel 3023820 X
SupportPostRearPanel 3015489 X
SupportPostShelf 3015492 XX
PanAssy‐Evap1Doors 3042234 X
PanAssy‐Evap2Doors 3020069 X
PanAssy‐Evap3Doors 3022670 X
FrontGrillAssy1Doors 3041170 X
FrontGrillAssy2Doors 3018400 X
FrontGrillAssy3Doors 3016857 X
ExtRearBottomPanel1Doors 3041401 X
ExtRearBottomPanel2Doors 3020018 X
ExtRearBottomPanel3Doors 3015027 X
