The vapor lines are connected to the fuel tank as shown.
They connect the fuel tank to the engine’s vapor port.
Figure 5-14, Figure 5-15 & Figure 5-16
Kohler engine shown
A. Fuel tank B. Fuel line
Figure 5-13
Kawasaki engine shown
A. Fuel tank
B. Vapor lines
C. Fuel evaporation
system filter
Figure 5-14
A
B
B
A
B
B
B
B
C
Kawasaki engine shown
A. Fuel tank
B. Vapor lines
C. Fuel evaporation
system filter
D. Carbon canister
Figure 5-15
Kohler engine shown
A. Fuel tank
B. Vapor lines
C. Fuel evaporation
system filter
Figure 5-16
A
B
B
B
B
C
B
D
A
B
B
B
B
C
