HUSTLER FasTrak SDX User Manual

REV C 5-4 121878
California requires all mowers using gasoline engines to
have this feature.
These canisters should be replaced every 5 years or if they
become damaged.
Fuel Evaporation System Filter
Hustler
®
FasTrak
®
SDX mowers have a fuel evaporation
system filter. This filter must be checked and replaced every
300 hours or annually whichever comes first. Figure 5-10 &
Figure 5-11
Fuel & Evaporative System Line Routings
These mowers have a fuel evaporative system installed.
There are two different types of rubber hoses that are
connected to the fuel tank. One is the fuel hose that is part of
the fuel system. The other is the vapor line that is part of the
fuel evaporative system.
The fuel hose is connected to the fuel tank as shown. It
connects the fuel tank to the engine’s fuel pump. Figure 5-12
& Figure 5-13
A. Carbon canister
B. Fuel evaporation system filter
Figure 5-9
Mowers without carbon canisters
A. Fuel evaporation system filter
Figure 5-10
B
A
A
Mowers with carbon canisters
A. Fuel evaporation system filter
B. Carbon canister
Figure 5-11
Kawasaki engine shown
A. Fuel tank B. Fuel line
Figure 5-12
B
A
A
B
B
