REV B 9-4 125816
Deck Functionality
Symptoms Probable causes Suggested Remedies
Grass is not being cut by side deck when mow-
ing crown of hills or other undulations.
Side deck hydraulic cylinders are not fully
extended to allow ±15 degree articulation.
Fully extend the side deck hydraulic cylinders
using the side deck lift switch.
Deck shuts off while mowing. Side deck angle switch is disengaged.
Move vehicle to flat ground and fully extend
side deck cylinders. Push the deck clutch
switch down to the disengaged "OFF" position.
Then, pull the deck clutch switch up to engage
the blade clutch and resume mowing.
Blade(s) do not rotate/clutch will not engage.
Side deck angle switch is disengaged.
Move vehicle to flat ground and fully extend
side deck cylinders. Push the deck clutch
switch down to the disengaged "OFF" position.
Then, pull the deck clutch switch up to engage
the blade clutch and resume mowing.
Side deck transport switch is engaged.
Manually release side deck transport latches -
both side decks must be unlatched. Fully
extend side deck cylinders, lowering side decks
to cutting position. Side decks must be fully
lowered to engage PTO.
Center deck will not lower into cutting position.
Transport latch is engaged when center deck
lift switched is pushed.
Push transport switch and raise deck lift to
maximum height. Pull and hold transport latch
back, release transport switch and allow deck
to lower to desired cut height.
Side decks will not lower into cutting position. Side deck transport switch is engaged.
Manually release side deck transport latches -
both side decks must be unlatched. Fully
extend side deck cylinders, lowering side decks
to cutting position.
