Customer Service Department
HUVITZ Co.,Ltd
2013. 08. 16
13 / 72
1. Fixation point
2. Control lever for changing enlargement
3. Removable eye-pieces
4. Knob for clamping the breath screen
5. Breath screen
6. Control handle for the slit rotation 90-0-90
7. Connecting plug of the projector lamp
8. Knurled ring for filters insertion
9. Movements (x y z)
10. Base with orthogonal movements
11. Shaped tabletop
12. Warning light of the SMPS
13. Main switch
14. Luminosity selector
15. SMPS box
16. Drawer
17. Toothed guides
18. Wheel protection Cases
19. Sliding plate
20. Knob to lock the projector
21. Scale for the projector position
22. Knob to lock the arm of the microscope
23. Hole cover
24. Knurled knob to lift the bulb holder
25. Ring for the vertical setting of the chin-rest
26. Locking pins for chin rest paper
27. Chin rest
28. Knobs to change the slit width
29. Pointer for the eye positioning
30. Head rest
31. Microscope
33. Knob to lock the base of the instrument
34. Knob to lock the microscope
35. Control handle for horizontal tilting
36. Control lever for vertical tilting
37. Microscope position stop
38. 90-0-90 determining the inclination of
the slit during rotation
39. Lamp cover
45. Microscope arm
49. An optical group of the slit projector
50. Patient’s handle
51. Chin rest fastening screw
52. Wheel
55. Mirror
56. Capture connector (For the image system)
57. Capture switch
58. Luminosity selector connector (Connecting to the SMPS)
59. Head rest module
60. LED Lamp (Option)
Part Name 2
