repairs illustrated below should all be carried out with the power cable
disconnected from the main supply plug. Please contact the suppliers for any other
problems that cannot be resolved by the operations des ibed below.
Please turn off the power s
witch before replacing lamps. Please place lamps after
cooling down. The heated lamp may burn your fingers.
t touch any other parts of glass tube with the bare fingers. Fingerprints, if any,
must be wiped off from the glass tube with alcohol
To replace the Halogen projection bulb proceed as follow.
Before doing anything else, disconnect the plug from the main supply socket;
Remove the Lamp cover(39),
(32) from the bulb stems;
out bulb; be careful , it could be very hot;
Replace it with a new one(12V30W Halogen) using the plastic envelope
(never touch the bulb whit fingers)
