© EUROHEAT DISTRIBUTORS (H.B.S) LTD. Nov 2006
E & OE Instructions Part number IN1141 Ed B
14
Continuous Operation
(Diagrams A2)
When the kindling is burning at its maximum rate, and a bed of embers has been formed, you can reload the
stove with dry seasoned split logs.
A bed of embers is when all the bottom is covered, and the embers glow in a ring around the riddling grate. Place
at least two logs in the stove.
Once lit the sliding air wash damper (2) is set to the middle position (see page 5). When in continuous use, no
further adjusting is necessary, this is done automatically. However, the temperature can be adjusted up or down
by the burn rate control knob (1).
Moving the control knob to the left reduces burning and prolongs the burning time.
Moving the control knob to the right rises the temperature and reduces the burning time.
(Diagrams A3)
With both dampers in the middle position, the highest efficiency is achieved.
