HWAM Vivaldi - Spare Parts

E & OE Instructions Part number IN1141 Ed B
21
© EUROHEAT DISTRIBUTORS (H.B.S) LTD. Nov 2006
Model Part Description Part No.
Vivaldi
Mozart
Beethoven
Beethoven H
Ravel
Hwam 30
Glass incl. gaskets HW22-0741
Set of Skamolex without smoke
plate*
HW22-0463
Smoke plate* HW22-0464
Cover plate for grate HW22-0350
Grate and frame, round
(not Hwam 30)
HW22-0742
Gasket set for door and ash pan HW22-0744
Gasket for glass HW22-0900
Hwam 30 Grate HW22-0143
Dali
Monet
Monet H
Hwam 60
Glass incl. gaskets HW22-0384
Set of Skamolex without smoke
plate*
HW22-0390
Smoke plate* HW22-0598
Cover plate for grate HW22-0350
Grate and frame, square HW22-0802
Gasket set for door and ash pan HW22-0144
Gasket for glass HW22-0900
Figaro
Glass incl. gaskets HW22-0064
Set of Skamolex without smoke
plate and front plate*
HW22-0063
Smoke plate and front plate* HW22-0688
Cover plate for grate HW22-0350
Grate HW22-0143
Gasket set for door and ash pan HW22-0065
Gasket for glass HW22-0900
Spare Parts
* Skamolex is also known as “mica”, it is the light coloured material lining the combustion chamber
* The Smoke Plate is the large Skamolex or Mica board at the rear of the combustion chamber
