Once the lower lugs are located, tilt the heater back towards the bracket and align the
upper bracket lugs into the corresponding slots at the top of the heater.
•
Insert the screws into the upper lug holes and screw down until the heater is locked
into place.
Electrical installation
The electrical installation must be carried out by a qualified electrician in
accordance with the current edition of the I.E.E. Wiring Regulations.
•
Connection should be made to the fixed wiring of the property via a double pole
fused spur with a break capacity of no less than 13amps.
•
Electrical connections should be made as follows:
Green/Yellow earth wire to the terminal marked “ E” or
Brown/Red live wire to the terminal marked “L”
Blue/Black neutral wire to the terminal marked “N”
