AUTOSET 6.3.
Use the AutoSet function to scan and program the unit High- or Low-Level to the distance detected. After the scan you will be prompted to accept the distance
measured. The High and Low level can also be manually adjusted in 'Setup'.
ADVANCED SETTINGS 6.4.
PARAMETER
DESCRIPTION
OPTIONS
Comms
Comms Adjust HART protocol settings
Device ID
Default 1
BaudRate
1200
Blanking
Blanking is a dead-band / non measured range. The unit cannot
measure within this range
Adjustable - recommended default
250mm (10")
Tracking
Adjust tracking response time for application. The faster the tracking, the
more responsive the measurement is, but the less smooth the output
signal
InstaTrack provides pulse by pulse live measurement
Slow
Medium
Fast
InstaTrack
Mapping
Mapping creates a digital 'map' of false echoes caused by problem
mounting and structures. Select 'ExecuteMap' to set a mapped distance,
conduct or delete Mapping. Select 'MappedDist' to view a previously
mapped distance
MappedDist
ExecuteMap
Set Map Dist
EchoSize
The unit will target this echo size (measured in signal voltage) during
operation. High values can increase stability but make the unit more
susceptible to false echoes. Lower values can make the unit less
sensitive and less likely to see false echoes
0.4 - 2.49V
Default 0.59V
Analog
Adjust Analog output. Switch from 4-20mA to 20-4mA and fine tune both
4mA current and 20mA current
4-20mA
20-4mA
Tune 4mA
Tune 20mA
Sensitivity
Increase or decrease the unit Automatic Sensitivity Control range. 20 is
maximum / highest sensitivity
0: Lowest
10: Default
20: Highest
WaveBoost
WaveBoost adds additional echo amplification on top of the Automatic
Sensitivity Control. WaveBoost should only be used if maximum
Sensitivity is not sufficient
0: Lowest (default)
20: Maximum
Factry Reset
Reset Restore all parameters to factory default
Yes / No
Device Info
Displays product type, serial number & software revision
Lock Code
Enable / Disable lock code
If enabled, select lock code number
Enable / Disable
Default Disabled
1-200
7. HART UNIVERSAL / COMMON PRACTICE COMMAND LIST
The Microflex-D supports the following HART Universal and Common commands:
COMMAND NO.
FUNCTION
0
Read unique identifier
1
Read Primary Variable
2
Read current and percent of range
3
Read current and four predefined dynamic variables
6
Write polling address
7
Read loop configuration
8
Read Dynamic Variable Classifications
11
Read unique ident. associated with tag
12
Read message
13
Read Tag, Description, Date
14
Read PV sensor information
15
Read output information
16
Read final assembly number
17
Write message
18
Write Tag, Description, Date
19
Write final assembly number
20
Read Long Tag
34
Write damping value
35
Write range values
44
Write PV units
57
Read unit tag, descriptor, date
58
Write unit tag, descriptor, date
59
Write number of response preambles
109
Burst mode control
Autoset
► Set Lo Level
Set Hi Level
Set Lo Level
SCANNING
Set Lo Level
► No
Yes
2.597m
