HydraMaster Corporation
Page 1-32 Boxxer 427
Frame Assembly Parts List
Item Part Number Description Qty
1 000-055-168 Frame, Steel - Welded - Boxxer 427 1
2 610-003-033 Assembly, Engine - Boxxer 427 (Fig. 1-12 - 1-13) 1
3 610-002-033 Assembly, Blower - Boxxer 427 (Fig. 1-16) 1
4 610-020-033 Assembly, Dash Upper - Boxxer 427 (Fig. 1-21 - 1-22) 1
5 610-019-033 Assembly, Dash Lower - Boxxer 427 (Fig. 1-24 - 1-25) 1
6 610-006-033 Assembly, Coolant Heat Exchanger (Fig. 1-29) 1
7 610-005-033 Assembly, Blower Heat Exchanger (Fig. 1-30) 1
8 610-003-033 Assembly, Exhaust - Boxxer 427 (Fig. 1-14) 1
9 000-093-092 Silencer, Boxxer 427 - Weldment 1
10 000-143-002 Screw, 1/4"-20UNC x 1.00" Lg. Hex Head 4
11 000-174-019 Washer, 1/4" Lock 4
12 000-020-063 Bushing, Snap, 0.55" O.D. x 0.312" I.D. 4
13 000-027-109 Cap, 2" x 2" Black 2
14 000-027-110 Cap, 2" x 3" Black 2
15 000-033-057 Clamp, 1" Cushion Loop 3
16 000-033-053 Clamp, 1-1/2" Cushion Loop 5
17 000-155-054 Spring, #10 Belleville Washer 9
18 000-174-001 Washer, #10 Flat 9
19 000-143-126 Screw, #10-24UNC x 0.50" Lg. Hex Head 9
20 000-105-012 Plate, Machine Serial I.D. 1
21 000-140-001 Rivet, 1/8" x 1/4" Aluminum 2
22 000-033-067 Clamp, 2" Cushion Loop 1
