Page 1-34 Boxxer 427
Figure 1-13 Engine Assembly - Front View
D-5572 Rev G
Engine Assembly Parts List
Item Part Number Description Qty
17
16
1
31
15
35
36
1 000-047-026 Engine, Briggs & Stratton 27HP 1
2 000-042-011 Housing, Air Cleaner - Daihatsu Engine 1
3 000-092-011 Mount, Engine 27 B&S - Boxxer 427 1
4 000-001-033 Adapter, Thermostat Housing 1
5 000-057-050 Gasket, Thermostat Housing Daihatsu Engine 2
