HydraMaster Corporation
Page 1-40 Boxxer 427
Blower Assembly Parts List
Item Part Number Description Qty
3 Fig. 1-20 Assembly, Water Box - Boxxer 427 1
4 Fig. 1-19 Assembly, Pump Mounting Bracket - Boxxer 427 1
5 000-015-814 Bracket, Dominator Mounting - Boxxer 421 1
6 000-042-061 Housing, Bell - Boxxer 427 1
7 000-109-112 Pulley, 3.50" Pump Drive 1
8 000-001-115 Adapter, Blower Flange To 3" M Slip - Boxxer 427 1
9 000-174-057 Washer, 3/8" Lock 5
10 000-143-018 Screw, 3/8"-16UNC x 1.00" Lg. Grade 8 10
11 000-010-123 Belt, EPDM 40" A-Section 1
12 000-174-105 Washer, 1-1/16" I.D. Self Aligning Spherical 2 Pc. Set 1
13 000-143-567 Screw, 1/2"-13UNC x 2.0" Lg. Hex HD Grd 8 Bo 1
14 000-174-007 Washer, 1/2" Flat 2
15 000-094-037 Nut, 1/2"-13UNC Hex 2-Way Locking - Z/P 1
16 000-015-897 Bracket, Water Box Support 1
17 000-143-001 Screw, 1/4"-20UNC x 0.75" Lg. Hex Head 6
18 000-174-019 Washer, 1/4" Lock 6
19 000-068-398 Hose, 3" I.D. x 3 Ply Silcone 1
20 000-033-013 Clamp, Size #48 Hose 2
21 000-052-142 Elbow, 3/8" FPT x FPT 2
22 000-174-021 Washer, 3/8" Lock 11
23 000-143-025 Screw, 3/8"-16UNC x 1.25" Lg. Hex Head Grd 8 3
24 000-020-019 Bushing, #H x 7/8" Bore 1
25 000-143-200 Screw, 3/8"-16UNC x 1.50" Lg. Grade 8 4
26 000-174-004 Washer, 5/16" Flat 3
27 000-174-032 Washer, 3/8" Flat 2
28 000-052-074 Nipple, 3/8" NPT Hex 2
29 000-152-010 Sleeve, 50 Series Split (Replacement) 1
30 000-078-424 Kit, Metal Ring Retainer 3 Pc. (Replacement) 1
31 000-039-053 Coupler, 50 Series 1
