HydraMaster Corporation
Page 1-50 Boxxer 427
Dash Upper Assembly Parts List
Item Part Number Description Qty
1 000-100-141 Panel, Upper Dash - Boxxer 427 1
2 000-100-145 Panel, Grill - Boxxer 427 1
3 000-157-008 Switch, Ignition 1
4 000-074-018 Meter, Rectangular w/o Bezel 1
5 000-025-002 Cable, Choke (3 Foot) 1
6 000-025-020 Cable, Throttle Kohler 1
7 000-084-011 Light, Red Led Indicator Mini 4
8 610-020-033 Assembly, Dash Guage Panel - Boxxer 427 (Fig. 1-23) 1
9 000-174-001 Washer, #10 Flat 18
10 000-174-014 Washer, #10 Lock 12
11 000-094-034 Nut, #10-24UNC Nylock 6
12 000-131-131 Trimlock, 3/8" x 1/8" Groove 1
13 000-143-134 Screw, #10-24UNC x 1.00" Lg Hex Head 4
14 000-143-126 Screw, #10-24UNC x 0.50" Lg. Hex Head 8
15 000-174-032 Washer, 3/8" Flat 1
16 000-174-057 Washer, 3/8" Lock 1
