HydraMaster Corporation
Boxxer 427 Page 1-63
Coolant Heat Exchanger Assembly Parts List
Item Part Number Description Qty
1 000-038-043 Heat Exchanger, Water To Water 1
2 000-052-086 Elbow, 3/8" NPT Street 1
3 000-052-528 Nipple, 3/8" M JIC x 3/8" NPT 2
4 000-052-083 Elbow, 3/8" NPT Street x 45° 1
5 000-143-001 Screw, 1/4"-20UNC x 0.75" Lg. Hex Head 4
6 000-174-019 Washer, 1/4" Lock 4
7 000-052-131 Elbow, 1" NPT x 1" Barb 2
8 000-125-194 Tube, Coolant Heat Exchager To Engine - Boxxer 427 1
9 000-068-250 Hose, 1" I.D. Green Stripe 1
10 000-068-250 Hose, 1" I.D. Green Stripe 1
11 000-068-250 Hose, 1" I.D. Green Stripe 1
12 000-052-648 Tee, 1" Barb x 1" Barb x 1" Barb 1
13 000-033-020 Clamp, Size #16 Hose 6
14 000-108-134 Protector, Coolant Hx Grey Silicone Blanket 1
