Page 1-70 Boxxer 427
70 Gallon Univesal Recovery Tank Assembly Parts List
Item Part Number Description Qty
1 000-159-128 Tank, 70 Gallon Universal Recovery - Weldment 1
2 610-003-015 Assembly, Cover - Dual Vac. (Fig. 1-35) 1
3 000-157-090 Float, Lever Switch 2
4 000-079-091 Kit, Dura-Flow APO - Production (Firg. 1-39) 1
5 000-049-152 Filter, Recovery Tank Basket 1
6 000-049-153 Filter, Flat - Recovery Tank 1
7 000-012-002 Block, 6 Post Terminal 1
8 000-015-932 Bracket, Flat Filter Securing - Universal Recovery Tank 1
9 000-049-154 Deflector, Air - Univeral Recovery Tank 1
10 000-057-206 Gasket, Adapter - Universal Recovery Tank 1
11 000-140-023 Rivet, AB8-6A Aluminum Pop 6
12 000-143-051 Screw, #8-32UNC x 0.75" Lg. Binder Head Phillips 2
13 000-094-059 Nut, #8-32UNF Nylock 2
14 000-086-008 Latch, Bungie 1
15 000-143-539 Screw, #6-32UNC x 0.50" Lg. Button Head Allen 2
16 000-094-063 Nut, #6-32UNC Nylock 2
17 000-106-019 Plug, 1-1/2" NPT 1
18 000-052-763 Nipple, 1-1/2" LPS Close s/s 1
19 000-169-022 Valve, 1-1/2" Full Port Ball 1
20 000-052-226 Insert,1-1/2" NPT x 1-1/2" Barb (Grey) 1
21 000-052-082 Elbow, 1/4" NPT Street x 45° 1
22 000-052-102 Insert, #46 (1/4" NPT x 3/8" Barb) 2
23 000-052-085 Elbow, 1/4" NPT Street 1
24 000-052-090 Tee, 1/4" NPT Branch M-F-F 1
25 000-169-120 Valve, Chemical & Hi-Temp Solenoid - 12 Volt 1
26 000-052-105 Insert, #68 (3/8" NPT x 1/2" Barb) 1
27 000-052-073 Nipple, 3/8" NPT x 1/4" NPT Hex 1
28 000-081-241 Label, Maintenance & Lubrication Schedule (Part of set) 1
29 000-174-029 Washer, 3/8" Rubber Back 2
30 000-094-034 Nut, #10-24UNC Nylock 4
31 000-033-023 Clamp, 3/4" Nylon Hose 2
