Hydro-Pro 5 - Maintenance; Maintenance Guidelines

- 24 -
NO
Part Name
ERP code NO
Part Name
ERP code
1
Front grill
28
Pipes temperature sensor collet 111900004
2
Front panel
1110040024
29
Pipes temperature sensor 111900004
3
Fan blade 113600017
30
Back grill 1110080042
4
Fan motor 11140053
31
Ambient temperature sensor 112200141
5
Fan motor bracket 1110130030
32
Ambient temperature sensor clip 113715001
6
maintain board 1110210031
33
Top cover 1110030042
7
Base tray 1110160102
34
Compressor wiring clip 110100038
8
Compressor 110100038
35
Water flow switch 112100021
9
Temperature sensor of water-in 112200133
36
isolation panel 1110110027
10
Titanium heat exchanger 113900077
37
controller box 1110120146
11
Panel on the side 1110021029
38
Cable fixing clamp-up
12
Drainage hole plug 113700077
39
Cable fixing clamp-down
113500007
13
Suction valve 112500019
40
Terminal blocks 112000008
14
Cable joints 114000184
41
controller box cover 1110150036
15
Pressure guage 110800001
42
PC board 11220183
16
Controller 112200149
43
Capacitance clamp 1110220010
17
Waterproof box 113712001
44
Capacitance 111300014
18
Panel on the side 1110021029
45
Transformator 112200064
19
Water inlet/outlet bolt 114000015
46
Fan motor capacitance 111300002
20
Suction pipe 1117991662
47
Pillar 1110070043
21
Exhaust pipe 1117991662
48
Grill on the side 1110090019
22
Pipe (4 way valve to evaporator) 1117991662
49
4 way valve 112600001
23
Pipe (4 way valve to heat exchanger) 1117991662
50
Pipe (heat exchanger to capillary) 1117991644
24
Water inlet/outlet screw cap 113900052
51
Liquid separator 1117991644
25
Capillary 1117991662
52 low pressure protection switch
112100003
26
Collection pipes 1117991662
53 high pressure protection switch
112100011
27 Evaporator Z1Z08Y313
10. Maintenance
(1) You should check the water supply system regularly to avoid the air entering the system and occurrence
of low water flow, because it would reduce the performance and reliability of HP unit.
(2) Clean your pools and filtration system regularly to avoid the damage of the unit as a result of the dirty of
clogged filter.
(3) You should discharge the water from bottom of water pump if HP unit will stop running for a long time
(specially during the winter season).
(4) In another way, you should check the unit is water fully before the unit start to run again.
(5) After the unit is conditioned for the winter season, he is preconize to cover the heat pump with special
winter heat pump.
(6) When the unit is running, there is all the time a little water discharge under the unit.
