If your system includes a Versi-Heat remote heater, see illustration below to see which layout
best fits your particular installation.
The heater can be installed vertical, horizontal or at an angle in the pumps
discharge plumbing (providing position DOES NOT allow air pockets to form
inside the housing). The heater can be installed up to 5-feet from the control
system, which is connected via a black 3-conductor and black 6-conductor
cord to the black receptacles provided at the control box..
IMPORTANT: It may be necessary to adjust the pressure switch (located
inside the heater enclosure) in some cases.
VERSI-HEAT CONSIDERATIONS
Pressure Switch Access
