Fail-Safe
SPECIFICATION FEATURES
Fasteners
Captive, stainless steel
tamperproof, T20 TORX ®-head
screws prevent unauthorized
access.
Housing
Die-formed 16 ga. Steel (FVS4P),
18 ga. Steel (FVS4M) with welded
and ground ends. Stainless steel
housing available.
Finish
Matte white electrostatically
applied, white powder coat finish.
Gloss white and anti-microbial
white painted finish available.
Gasket
Concealed, polyurethane end
gaskets inhibit the entrance of
environmental contaminants.
Lens
Nominal 0.125”, UV stabilized,
clear Pattern 12, impact-resistant,
prismatic polycarbonate refractor
for high efficiency, low surface
brightness and maximum strength.
Opal smooth available. .187”
thick clear Pattern 12 prismatic
polycarbonate available.
Lifetime Lens Warranty
LEDs
Available with 3000K, 3500K,4000K,
5000K with minimum of 80CRI.
Projected life is 50,000 hours at
70% lumen maintenance.
Lens Retention
The FVS4P double wall lens
channel captivates lens to prevent
unauthorized fixture penetration.
Screws along each side to ensure
maximum lens captivation. FVS4M
incorporates (2) tamper resistant
screws, one on each endcap.
Transformer/Driver
Electronic driver 120V-277V, 0-10V,
dimming standard.
Compliance
UL listed for damp location.
Wet location listed under covered
ceiling optional. (FVS4P only).
Warranty
5 Year warranty on LED’s and
electrical. Lifetime warranty if
fixture found to be inoperative due
to physical abuse for duration of
the installation.
FVS4
FVS4W
LD4 LED
4" Wide
2',3',4',8' Length
Polycarbonate Lens
Vandal Resistant
Ceiling/Wall
PS519165EN
June 14, 2019 2:11 PM
Designed with asthetics as a high priority, the tasteful FVS4 combines
style with strength. Ideally suited for high abuse areas, Fail-Safe's
FVS4 is offered as ceiling- or wall-mounted, to provide general ambient
illumination. Designed for use in public access areas where vandalism
may occur and for areas that must maintain a clean, well-illuminated
appearance.
Ideal for schools, dormitories, hallways, locker rooms, shower facilities,
stairwells, restrooms, and storage facilities.
DESCRIPTION
ENERGY DATA
For Energy Management related
technical data to support the
performance of this fixture series,
refer to the ordering information for
input wattage.
FVS4W
Construction
Housing
Listing
FVS4MFVS4P
18GA Steel
16GA Steel
ETL
Listed Damp
Location
ETL
Damp,
Wet Optional
Set Screws
on Endcaps
Screws along
fixture edge
Length
FVS4P
# Screws
each side
2’
3’
4’
8’
2
2
3
5
PREMIUM MODERA
4.00 in
102mm
3.75 in
95mm
CEILING or WALL MOUNT
FVS4
Catalog #
Project
Comments
Prepared by
Type
Date
