Hyperion EOS 5i DP AC/DC User Manual

Pb Mode (lead-acid battery)
PB CHARGE
C=3.0A 12Vpack
BATT TYPE
PB CHARGE
C=3.0A 12Vpack
DEC INC
ENTER
PB CHARGE
C=3.0A 12Vpack
DEC INC
ENTER
BATTERY CHECK
WAIT PLEASE. . . .
START
CHG 0:00 00000
Pb + 3.0 1.200
INC
DEC
PB DISCHARGE
D=0.50A 12Vpack
ENTER
DEC INC
PB DISCHARGE
D=0.50A 12Vpack
ENTER
DEC INC
BATTERY CHECK
WAIT PLEASE. . . .
START
CHG 0:00 00000
Pb - 3.0 1.200
PB DISCHARGE
D=0.50A 12Vpack
Back to NiCd
Setting charge current
PB CHARGE
C=3.0A 12Vpack
Adjust and find the desired charge current which ranges from 0.1A to 5.0A with INC &
DEC buttons. Press the ENTER button to confirm setting
Setting total battery voltage for Lead-Acid Battery
PB CHARGE
C=3.0A 12Vpack
Select the proper total battery voltage to be charged or discharged with INC & DEC
buttons – 2V, 4V, 6V, 8V, 10V, and 12V [2V per cell types only]
Setting discharge current
PB DISCHARGE
D=0.50A 12Vpack
Adjust and find the desired discharge current from 0.10A to 1.00A (0.01A per step) with
INC & DEC button. Press the ENTER button to confirm setting.
Displays during charge, discharge, and cycle
CHG 030:25 00000
NC + 3.00A 10 .75V
NC: NiCd
NM: NiMH
LP: LiPo
Pb: Pb
DCH 030:25 00000
NC - 3.00A 10 .75V
CHG: charge
DCH: discharge
C→D: cycle
D→C: cycle
DELAY TIME
5 : 00

Hyperion EOS 5i DP AC/DC Specifications

General

Brand	Hyperion
Model	EOS 5i DP AC/DC
Category	Battery Charger
Language	English
