HyperX QuadCast S Installation Guide

Document No. 480HX-HMIQ1S.A01
HyperX QuadCast
TM
S
Page 16 of 17
Installing the Mount Adapter
1. Secure the included mount adapter onto a microphone boom arm. The mount adapter supports 3/8”
and 5/8” thread sizes.
2. Remove both the thumb screw and nut from the microphone stand.
3. Remove the microphone stand from the microphone.
4. Align the mount adapter with the microphone mount holes and secure the adapter with the thumb
screw and nut.

HyperX QuadCast S Specifications

General

Type	Table microphone
Bit rate	16 bit
Sample rate	48 kHz
Microphone mute	Yes
Voice coil type	Condenser
Microphone frequency	20 - 20000 Hz
Microphone sensitivity	-36 dB
Microphone direction type	Omnidirectional/Bidirectional microphone
Cables included	USB Type-A to USB Type-C
Device interface	USB
USB connector type	USB Type-C
Connectivity technology	Wired
Cable length	3 m
Mounting type	Table
Product color	Black
Output impedance	32 Ω
Total Harmonic Distortion (THD)	0.05 %
Line-out Signal-to-Noise Ratio (SNR)	90 dB
Operating voltage	5 V
Power consumption	229 mA

Weight and Dimensions

Microphone weight	254 g
