HyperX QuadCast S Installation Guide

Document No. 480HX-HMIQ1S.A01
HyperX QuadCast
TM
S
Page 4 of 17
Specifications
Microphone
Power consumption: 5V 220mA (white light)
Sample/bit rate: 48kHz/16-bit
Element: Electret condenser microphone
Condenser type: Three 14mm condensers
Polar patterns: Stereo, Omnidirectional, Cardioid, Bidirectional
Frequency response: 20Hz - 20kHz
Sensitivity: -36dB (1V/Pa at 1kHz)
Cable length: 3m
Weight:
• Microphone: 254g
• Shock mount and stand: 360g
• Total with USB cable: 710g
Headphone Output
Impedance: 32 Ω
Frequency response: 20Hz - 20kHz
Maximum power output: 7mW
THD: ≤ 0.05% (1kHz/0dBFS)
SNR: ≥ 90dB (1kHZ, RL=∞)

HyperX QuadCast S Specifications

General

Type	Table microphone
Bit rate	16 bit
Sample rate	48 kHz
Microphone mute	Yes
Voice coil type	Condenser
Microphone frequency	20 - 20000 Hz
Microphone sensitivity	-36 dB
Microphone direction type	Omnidirectional/Bidirectional microphone
Cables included	USB Type-A to USB Type-C
Device interface	USB
USB connector type	USB Type-C
Connectivity technology	Wired
Cable length	3 m
Mounting type	Table
Product color	Black
Output impedance	32 Ω
Total Harmonic Distortion (THD)	0.05 %
Line-out Signal-to-Noise Ratio (SNR)	90 dB
Operating voltage	5 V
Power consumption	229 mA

Weight and Dimensions

Microphone weight	254 g
