How to Drive
5
─
68
─
Parking for LPG Truck
1. When entering the garage or parking for a long period, close the fuel outlet
valve, and wait for the engine to stop naturally. Then, turn off the key switch.
2. Avoid parking in direct sunlight when parking outdoors for long periods during
the summer, etc.
Replacement of LPG Container
1. Conrm that the containers fuel outlet
valve is closed.
2. Close the green handle on the valve
assembly, if equipped.
3. Disconnect the valve assembly from
the outlet valve.
4. Loosen and swing up the lock screw,
then pull the lock pin and the swing
LPG bracket 180 degree. The LPG
bracket is locked by the lock pin at
the swung position.
5. Push down the LPG tank bracket
and replace the LPG tank.Tighen the
belts.
6. Pull up the LPG tank.
7. Pull the lock pin and swing the LPG
tank to the normal operating position.
8. Tighten the lock screw.
Lock screw
HandleLock pin
