Parking for LPG Truck
1. When entering the garage or parking for a long period, close the fuel outlet
valve, and wait for the engine to stop naturally. Then, turn off the key switch.
2. Avoid parking in direct sunlight when parking outdoors for long periods during
the summer, etc.
Replacement of LPG Container
1. Conrm that the containers fuel outlet
valve is closed.
2. Close the green handle on the valve
assembly, if equipped.
3. Disconnect the valve assembly from
the outlet valve.
4. Loosen and swing up the lock screw,
then pull the lock pin and the swing
LPG bracket 180 degree. The LPG
bracket is locked by the lock pin at
the swung position.
5. Push down the LPG tank bracket
and replace the LPG tank.Tighen the
belts.
6. Pull up the LPG tank.
7. Pull the lock pin and swing the LPG
tank to the normal operating position.
8. Tighten the lock screw.
Lock screw
HandleLock pin
Handling during Winter
1. Engine oil, transmission oil, differential gear oil, hydraulic oil
Refer to the table of Recommended Oils and Grease on page 111~114, and
select oils suitable to the temperature.
2. Cooling water
40% of long-life coolant is mixed into the cooling water, and replacement
is not necessary for two years. Only the water level needs to be inspected.
The freezing point of the cooling water with 40% long-life coolant is ─24°C,
so operation during summer and winter is normally possible. (Increase the
amount of long-life coolant according to the temperature when using the lift
truck in cold climates colder than ─24°C during the winter.)
Cooling water capacity
7.5 (K21 engine)
7.8 (K25 engine)
7.5
(4TNE92 Diesel)
7.8
(4TNE98 Diesel)
● Do not run when the LPG tank is
in the swung position and swung-
down position.
● To open hood, need to swing the
LPG tank.
● Do not replace the LPG tank on the
way to swing the LPG tank.
● Route the LPG hose not to
protrude from the truck outline.
● To swing up the bracket without
LPG tank, hold the bracket by both
hand and swing up carefully.
● To avoid swing up the bracket
accidentally, do not apply any hard
impacts to the bracket when the
bracket is swung down without
LPG tank.
CAUTION
