13
5. Status Indications
5.1 LCD Icon
Icon Radio Status
More bars indicate more remaining battery power.
The battery power runs out. Recharge or replace the battery.
The radio detects no signal.
More bars indicate stronger signal strength.
In analog mode, the radio transmits when the
PTT
key is pressed.
The radio operates in low power mode.
The radio operates in high power mode.
The radio is scanning.
The radio stays on an active channel.
DM Direct Mode: The radio transmits and receives directly.
RM Repeater Mode: The radio transmits and receives through a repeater.
The VOX feature is enabled.
The speaker is turned on.
The radio operates in silent mode.
An accessory is connected.
The Monitor feature is enabled.
The Scrambler feature is enabled.
The Squelch feature is enabled.
5.2 LED Indicator
LED Indicator Radio Status
Flashes green The radio is being turned on.
Glows red The radio is transmitting.
