Hytera MD785 User Manual

1
Items in the Package ------------------------------------------------------------- 2
Product Overview -----------------------------------------------------------------2
Front Panel ----------------------------------------------------------------------------------- 2
Rear Panel -----------------------------------------------------------------------------------3
Programmable Keys -----------------------------------------------------------------------3
LCD Icon -------------------------------------------------------------------------------------- 3
LED Indicator --------------------------------------------------------------------------------3
Installation --------------------------------------------------------------------------- 4
Instructions -----------------------------------------------------------------------------------4
Installation Tools ---------------------------------------------------------------------------4
Installation Parts ----------------------------------------------------------------------------4
Installation Procedure ---------------------------------------------------------------------4
Basic Operations ------------------------------------------------------------------ 5
Turning the Radio On/Off ----------------------------------------------------------------- 5
Initial Registration ---------------------------------------------------------------------------5
Adjusting the Volume ---------------------------------------------------------------------- 5
Selecting a Subgroup --------------------------------------------------------------------- 5
Selecting a Group Contact --------------------------------------------------------------5
Inputting via Keypad -----------------------------------------------------------------------5
Managing the Contact --------------------------------------------------------------------- 5
Call Services ------------------------------------------------------------------------ 6
Private Call -----------------------------------------------------------------------------------6
Group Call ------------------------------------------------------------------------------------7
Emergency Call -----------------------------------------------------------------------------8
Contents
Message Services ----------------------------------------------------------------- 8
Available Features ----------------------------------------------------------------9
Troubleshooting -------------------------------------------------------------------10
Care and Cleaning ----------------------------------------------------------------11
Optional Accessories ------------------------------------------------------------11

Hytera MD785 Specifications

General

Channel Capacity	1024
Zone Capacity	64
Operating Voltage	13.6V ±15%
Dimensions	174 x 60 x 200 mm
Weight	1.7 kg
Channel Spacing	12.5 / 20 / 25 KHz
Operating Temperature	-30°C to +60°C
Frequency Stability	±0.5 ppm
Antenna Impedance	50Ω
Receiver Sensitivity Digital	0.3μV / BER 5%
IP Rating	IP54
GPS	Optional
Bluetooth	Optional
Frequency Range	VHF: 136-174 MHz, UHF: 400-470 MHz
Digital Protocol	DMR
Vocoder Type	AMBE++
Power Output	VHF: 1-5 W, UHF: 1-4 W
Digital/Analog	Both
Display	LCD
