Hytera MD785 User Manual

1
Contents
Items in the Package ------------------------------------------------------------- 2
Product Overview -----------------------------------------------------------------2
Front Panel ----------------------------------------------------------------------------------- 2
Rear Panel -----------------------------------------------------------------------------------2
Programmable Keys -----------------------------------------------------------------------3
LCD Icon -------------------------------------------------------------------------------------- 3
LED Indicator --------------------------------------------------------------------------------4
Installation --------------------------------------------------------------------------- 4
Instructions -----------------------------------------------------------------------------------4
Installation Tools ---------------------------------------------------------------------------4
Installation Part ------------------------------------------------------------------------------4
Installation Procedure ---------------------------------------------------------------------5
Basic Operations ------------------------------------------------------------------ 5
Turning the Radio On/Off ----------------------------------------------------------------- 5
Adjusting the Volume ---------------------------------------------------------------------- 5
Selecting a Zone ---------------------------------------------------------------------------- 5
Selecting a Channel -----------------------------------------------------------------------5
Inputting via Keypad -----------------------------------------------------------------------5
Managing the Contact --------------------------------------------------------------------- 5
Call Services ------------------------------------------------------------------------ 6
Private Call -----------------------------------------------------------------------------6
Group Call ------------------------------------------------------------------------------7
Call on Analog Channel (Without Signaling) ----------------------------------7
Emergency Call -----------------------------------------------------------------------------7
Message Services -----------------------------------------------------------7
Available Features ----------------------------------------------------------------8
Troubleshooting -------------------------------------------------------------------9
Care and Cleaning ----------------------------------------------------------------10
Optional Accessories ------------------------------------------------------------10

Hytera MD785 Specifications

General

Channel Capacity	1024
Zone Capacity	64
Operating Voltage	13.6V ±15%
Dimensions	174 x 60 x 200 mm
Weight	1.7 kg
Channel Spacing	12.5 / 20 / 25 KHz
Operating Temperature	-30°C to +60°C
Frequency Stability	±0.5 ppm
Antenna Impedance	50Ω
Receiver Sensitivity Digital	0.3μV / BER 5%
IP Rating	IP54
GPS	Optional
Bluetooth	Optional
Frequency Range	VHF: 136-174 MHz, UHF: 400-470 MHz
Digital Protocol	DMR
Vocoder Type	AMBE++
Power Output	VHF: 1-5 W, UHF: 1-4 W
Digital/Analog	Both
Display	LCD
