Job data is saved as a Comma-Separated Value (.CSV) file that can be opened in any standard spreadsheet program.
The file will display the column headings shown below, with each row representing a separate trigger pull event.
JOB DATA FILE FORMAT
DATE Month, day and year of the bolting operation (format: mm/dd/yy)
TIME The time of the bolting operation (format: hh:mm:ss) (24hr)
DURATION Time the motor was running during the bolting operation (in seconds)
JID Job Identifier
PID Profile Identifier
PTYPE Profile Type designation associated with function. See page 31.
TORQUE* Torque value set in the tool during operation
ANGLE Angle value in degrees set in the tool for the operation
RELEASE Angle value in degrees for releasing the tool
FASTENER Fastener type (also defines direction of rotation)
UNITS Units for torque (e.g. ft-lb, Nm, etc.)
T/L Indicates if the tool was set to tighten or loosen
ROTATIONS Number of rotations turned (reported only for Rotations operations).
RESULT Indicates successful operation, or other message (see Appendix)
FINAL TORQUE* Final reported torque.
LEVEL Access level of the user completing the operation (L1, L2, etc.)
USER ID User identification entered by the user; if supplied
* Available in future firmware release.
DATE TIME DURATION JID PID PTYPE TORQUE ANGLE RELEASE FASTENER UNITS T/L ROTATIONS RESULT
FINAL
TORQUE
LEVEL USER ID
1/30/20 14:04:49 6 ADHOC CWP TAR 500 5 3 HWR ft-lb T ETR
L4 TEAM_08
1/30/20 14:02:53 29 ADHOC CWP TAR 500 5 3 HWR ft-lb T OK 518 L4 GIANTS21
1/30/20 14:01:32 23 ADHOC CWP TAR 600 10 5 HWR ft-lb T OK 645 L4 DAVE
1/30/20 14:00:30 34 ADHOC CWP TAR 600 5 5 HWR ft-lb T OK 590 L4 DAVE
1/30/20 13:59:37 5 ADHOC CWP TAR 300 5 5 HWR ft-lb L OK L4 DAVE
1/30/20 10:19:10 5 WHEEL003 CWP TCK 500 5 HWR ft-lb T OK 500 L1 JOE
1/29/20 14:07:18 2 WHEEL002 CWP TAR 3000 5 HWR ft-lb R-L OK L4
1/29/20 14:07:58 2 WHEEL002 123ABC TAR 500 5 5 HWR ft-lb R-T ETR L4
1/28/20 14:19:16 32 TC1 CWP TAR 900 5 5 HWR ft-lb T OK 919 L4
1/23/20 15:56:53 24 SNUG1 TEST8 SRF 150 0 7 HWR ft-lb T ETR L4 UID1234
1/23/20 15:56:25 3 SNUG1 TEST9 SRF 150 0 7 HWR ft-lb T ME L4 UID1234
1/23/20 15:55:21 13 SNUG1 TEST10 SRF 150 0 7 HWR ft-lb T MHS L2 UID1234
1/23/20 15:54:53 14 SNUG1 CWP SRF 3000 0 7 HWR ft-lb L OK L4 UID1234
1/23/20 15:54:23 14 SNUG1 CWP SRF 150 0 7 HWR ft-lb T OK L4 UID1234
1/13/20 12:20:26 13 RO1 123ABC ROT 7 RH ft-lb T 0.4 OK L4 ERAN
1/13/20 12:03:02 5 TA1 CWP RAR 10 7 RH Nm T OK 303 L3 RANDY
(CONT’D.)(CONT’D.)
