LITHIUM SERIES® II ELECTRIC TORQUE TOOL USER INTERFACE GUIDE

The Torque function can be adjusted directly from the Home Screen and also may be accessed from the Main Menu.
Adjust the torque value using the left and right buttons to increase or decrease the torque to the nearest ft-lb (or other
unit selected in the settings menu). The Torque value may be adjusted from the minimum to the maximum calibrated
value of the tool. The Torque value is subject to limits set in the Settings menu.
A release angle may be included in the Torque operation to take the tension o the motor allowing the tool to be released
from the application. The Release may be adjusted as needed through the Release option on the Main Menu. The Torque
function may also include an optional angle applied within the same trigger pull. During a Torque operation with Angle
and/or Release, the Torque value is always applied first followed by Angle and then Release.
While adjusting the Torque value, if the user continues to hold the right button after reaching the minimum Torque value
the screen changes to the Snug function. The Snug function allows the user to continue to decrease torque but at an
accuracy less than the calibrated Torque function.
TORQUE
. BASIC BOLTING
